400i Features
- COLOR TFT LCD Solid graphics
- 3D Simulation Distance to go UL approval
- Preset.
- I0 reference signals.
- DISPLAY-OFF mode.
- Multi point axis error compensation
- Absolute & incremental.
- INCH/ MM
- Speed and counting alarms.
- Data back-up.
- Resolutions from 0,1 to 500 microns. Hysterisis
- Part Centering Scaling Factor Sleep Mode
- Software limit set up Feedback Error Monitoring Angular Axis
- 20 Work Offsets
- Bolt Hole( with most recent data in memory)
- Linear hole pattern
- Part Skew (alignment)
- Tool Radius Compensation
- Arc Machining
- Calculator
- Machine Axis Rotation
- Reader head movement on roller bearings. Accuracy +/- 10 microns.
- Maximum speed 30 m/min.
- 3 mts. Armored cable
Common Prokit Packages
EXTREME MC 01
Axis Travel (Maximum): 12 X 30 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i ,MKT 32, MKT 77, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,880
EXTREME MC 02
Axis Travel (Maximum): 12 X 36 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 32, MKT 92, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,880
EXTREME MC 03
Axis Travel (Maximum): 12 X 32 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 82, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,880
EXTREME MC 04
Axis Travel (Maximum): 18 X 40 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 47, MKT 102, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,952
EXTREME MC 05
Axis Travel (Maximum): 16 X 36 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 92, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,952
Additional Prokit Packages
EXTREME MC 06
Axis Travel (Maximum): 14 X 30 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i ,MKT 37, MKT 77, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,923
EXTREME MC 07
Axis Travel (Maximum): 14 X 32 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 37, MKT 82, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,923
EXTREME MC 08
Axis Travel (Maximum): 14 X 36 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 37, MKT 92, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,923
EXTREME MC 09
Axis Travel (Maximum): 16 X 40 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 102, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,965
EXTREME MC 10
Axis Travel (Maximum): 16 X 40 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 102, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,965
Additional Prokit Packages - 16" knee mount
EXTREME MC 1K
Axis Travel (Maximum): 12 X 30 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 32, MKT 77, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 2K
Axis Travel (Maximum): 12 X 36 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 32, MKT 92, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 6K
Axis Travel (Maximum): 14 X 30 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 37, MKT 77, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 7K
Axis Travel (Maximum): 14 X 32 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 37, MKT 82, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 8K
Axis Travel (Maximum): 14 X 36 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 37, MKT 82, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 9K
Axis Travel (Maximum): 16 X 30 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT77, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 3K
Axis Travel (Maximum): 16 X 32 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 82, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $3,082
EXTREME MC 5K
Axis Travel (Maximum): 16 X 36 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 92, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $3,159
EXTREME MC 10K
Axis Travel (Maximum): 16 X 40 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 102, MKT 47, MILL-L/COMBO, Z KNEE KIT
List Price: $3,159
EXTREME MC 4K
Axis Travel (Maximum): 18 X 40 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 102, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $3,159
Additional Prokit Packages - 18" Knee Mount
EXTREME MC 11K
Axis Travel (Maximum): 12 X 30 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 32, MKT 77, MKT 47, MILL-M/COMBO, Z KNEE KIT
List Price: $3,111
EXTREME MC 12K
Axis Travel (Maximum): 12 X 36 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 32, MKT 92, MKT 47, MILL-M/COMBO, Z KNEE KIT
List Price: $3,111
EXTREME MC 18K
Axis Travel (Maximum): 14 X 36 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 37, MKT 92, MKT 47, MILL-M/COMBO, Z KNEE KIT
List Price: $3,111
EXTREME MC 13K
Axis Travel (Maximum): 16 X 32 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 82, MKT 47, MILL-L/COMBO,Z KNEE KIT
List Price: $3,111
EXTREME MC 15K
Axis Travel (Maximum): 16 X 36 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 42, MKT 92, MKT 47, MILL-L/COMBO, Z KNEE KIT
List Price: $3,175
EXTREME MC 14K
Axis Travel (Maximum): 18 X 40 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 400i, MKT 47, MKT 102, MKT 47, MILL-L/COMBO, Z KNEE KIT
List Price: $3,175
4-axis Upgrade to Knee kits (Quill)
UPGRADE TO 4-axis kit
Includes: 400i-P 4-axis Display, MKT17 (6") Linear Scale, Quill-kit Bracket
List Price: $839
