30i-M Features
- Preset.
- I0 reference signals.
- DISPLAY-OFF mode.
- Multi point axis error compensation
- Absolute & incremental.
- INCH/ MM
- Speed and counting alarms.
- Data back-up.
- Resolutions from 0,1 to 500 microns. Hysterisis
- Part Centering Scaling Factor Sleep Mode
- Software limit set up Feedback Error Monitoring Angular Axis
- 20 Work Offsets
- Bolt Hole( with most recent data in memory)
- Linear hole pattern
- Part Skew (alignment)
- Tool Radius Compensation
- Arc Machining
- Calculator
- Machine Axis Rotation
- Reader head movement on roller bearings. Accuracy +/- 10 microns.
- Maximum speed 30 m/min.
- 3 mts. Armored cable
Common Prokit Packages
EXTREME 01
Axis Travel (Maximum): 12 X 30 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM ,MKT 32, MKT 77, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,591
EXTREME 02
Axis Travel (Maximum): 12 X 36 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 32, MKT 92, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,591
EXTREME 03
Axis Travel (Maximum): 16 X 32 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 82, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,591
EXTREME 04
Axis Travel (Maximum): 18 X 40 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 47, MKT 102, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,663
EXTREME 05
Axis Travel (Maximum): 16 X 36 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 92, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,663
Additional Prokit Packages
EXTREME 06
Axis Travel (Maximum): 14 X 30 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM ,MKT 37, MKT 77, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,591
EXTREME 07
Axis Travel (Maximum): 14 X 32 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 37, MKT 82, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,591
EXTREME 08
Axis Travel (Maximum): 14 X 36 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 37, MKT 92, MKT 17, MILL-M/COMBO, Z QUILL KIT
List Price: $2,591
EXTREME 09
Axis Travel (Maximum): 16 X 40 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 102, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,663
EXTREME 10
Axis Travel (Maximum): 16 X 40 X 6
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 102, MKT 17, MILL-L/COMBO, Z QUILL KIT
List Price: $2,663
Prokit Package (16" Knee Mount)
EXTREME 1K
Axis Travel (Maximum): 12 X 30 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 32, MKT 77, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 2K
Axis Travel (Maximum): 12 X 36 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 32, MKT 92, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 6K
Axis Travel (Maximum): 14 X 30 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 37, MKT 77, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 7K
Axis Travel (Maximum): 14 X 32 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 37, MKT 82, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 8K
Axis Travel (Maximum): 14 X 36 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 37, MKT 92, MKT 42, MILL-M/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 9K
Axis Travel (Maximum): 16 X 30 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT72, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 3K
Axis Travel (Maximum): 16 X 32 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 82, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $2,706
EXTREME 5K
Axis Travel (Maximum): 16 X 36 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 92, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $2,771
EXTREME 10K
Axis Travel (Maximum): 16 X 40 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 102, MKT 47, MILL-L/COMBO, Z KNEE KIT
List Price: $2,771
EXTREME 4K
Axis Travel (Maximum): 18 X 40 X 16
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 102, MKT 42, MILL-L/COMBO, Z KNEE KIT
List Price: $2,771
Prokit Package (18" Knee Mount)
EXTREME 11K
Axis Travel (Maximum): 12 X 30 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 32, MKT 77, MKT 47, MILL-M/COMBO, Z KNEE KIT
List Price: $2,735
EXTREME 12K
Axis Travel (Maximum): 12 X 36 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 32, MKT 92, MKT 47, MILL-M/COMBO, Z KNEE KIT
List Price: $2,735
EXTREME 18K
Axis Travel (Maximum): 14 X 36 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 37, MKT 92, MKT 47, MILL-M/COMBO, Z KNEE KIT
List Price: $2,735
EXTREME 13K
Axis Travel (Maximum): 16 X 32 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 82, MKT 47, MILL-L/COMBO,Z KNEE KIT
List Price: $2,735
EXTREME 15K
Axis Travel (Maximum): 16 X 36 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 42, MKT 92, MKT 47, MILL-L/COMBO, Z KNEE KIT
List Price: $2,787
EXTREME 14K
Axis Travel (Maximum): 18 X 40 X 18
DRO, X Scale, Y Scale, Mounting Hardware: 30iM, MKT 47, MKT 102, MKT 47, MILL-L/COMBO, Z KNEE KIT
List Price: $2,787
