Fagor Automation 400i Lathe Prokit

400i Features

• COLOR TFT LCD
• Solid graphics
• 3D Simulation
• Distance to go
• UL approval
• 20 Tool offsets
• Direct mm/inch conversion.
• Axis RESET (to zero).
• Axis PRESET.
• Absolute / incremental.
• Taper calculation
• Data Eeprom back-up.
• Machine error compensation
• Fine/coarse display resolution. selection from Keyboard:
• 0.005 / 0.01 micron. (.0002 / .001)
• HOLD function.
• Radius/diameter.

MT Scales Features

Reader head movement on roller bearings.

Accuracy +/- 10 microns.

Maximum speed 30 m/min.

Sealing protection IP 53.

Armored cables

Threading Assistance Package Lathe threading feature for 400i DRO. Items included:

Encoder - (S2500C)

Cable for encoder (XC-C4-5-D)

Encoder coupling (AF Type)

Mounting Bracket (To be supplied by customer) (Drawing enclosed)

Fagor Prokits come standard with Display Arm for Headstock Mounting. PROKIT-TC1 6" Travel Mini-Scale for X PROKIT-TC1 Axis Travel (Maximum): 6 X 36 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 17, CT92, Universal Lathe S, T-arm, EC 3 PD List Price: $2,706 PROKIT-TC2 Axis Travel (Maximum): 6 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 17, CT102, Universal Lathe S, T-arm, EC 3 PD List Price: $2,706 8" Travel Mini-Scale for X PROKIT-TC3 Axis Travel (Maximum): 8 X 36 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 22, CT92, Universal Lathe S, T-arm, EC 3 PD List Price: $2,706 PROKIT-TC4 Axis Travel (Maximum): 8 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 22, CT102, Universal Lathe S, T-arm, EC 3 PD List Price: $2,741 PROKIT-TC5 Axis Travel (Maximum): 8 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 22, CT124, Universal Lathe S, T-arm, EC 3 PD List Price: $2,885 8" Travel Slim-Line Scale for X PROKIT-TC6 Axis Travel (Maximum): 8 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 22, CT134, Universal Lathe M, T-arm, (two) EC 4 PD List Price: $2,959 PROKIT-TC7 Axis Travel (Maximum): 8 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 22, CT154,Universal Lathe M, T-arm, (two) EC 4 PD List Price: $3,103 PROKIT-TC8 Axis Travel (Maximum): 8 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 22, CT174, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,174 PROKIT-TC9 Axis Travel (Maximum): 8 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 22, CT204, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,463 10" Travel Mini-Scale for X PROKIT-TC10 Axis Travel (Maximum): 10 X 36 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 27, CT92, Universal Lathe S, T-arm, EC 4 PD List Price: $2,735 PROKIT-TC11 Axis Travel (Maximum): 10 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 27, CT102, Universal Lathe S, T-arm, EC 4 PD List Price: $2,779 PROKIT-TC12 Axis Travel (Maximum): 10 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MMKT 27, CT124, Universal Lathe S, T-arm, EC 4 PD List Price: $2,923 10" Travel Slim-Line Scale for X PROKIT-TC13 Axis Travel (Maximum): 10 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT134, Universal Lathe M, T-arm, (two) EC 4 PD List Price: $3,067 PROKIT-TC14 Axis Travel (Maximum): 10 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT154, Universal Lathe M, T-arm, (two) EC 4 PD List Price: $3,168 PROKIT-TC15 Axis Travel (Maximum): 10 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT174, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,255 PROKIT-TC16 Axis Travel (Maximum): 10 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT184, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,385 PROKIT-TC17 Axis Travel (Maximum): 10 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT204, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,818 PROKIT-TC18 Axis Travel (Maximum): 10 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT244, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $4,294 PROKIT-TC19 Axis Travel (Maximum): 10 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT284, Universal Lathe M, T-arm, (two)EC 6PD List Price: $4,799 PROKIT-TC20 Axis Travel (Maximum): 10 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 27, CT304, Universal Lathe M, T-arm, (two) EC 6PD List Price: $5,016 12" Travel Slim-Line Scale for X PROKIT-TC21 Axis Travel (Maximum): 12 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT102, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,822 PROKIT-TC22 Axis Travel (Maximum): 12 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT124, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,923 PROKIT-TC23 Axis Travel (Maximum): 12 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT134, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,139 PROKIT-TC24 Axis Travel (Maximum): 12 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT154, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,240 PROKIT-TC25 Axis Travel (Maximum): 12 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT174, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,313 PROKIT-TC26 Axis Travel (Maximum): 12 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT184, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,457 PROKIT-TC27 Axis Travel (Maximum): 12 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT204, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $3,896 PROKIT-TC28 Axis Travel (Maximum): 12 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT244, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,265 PROKIT-TC29 Axis Travel (Maximum): 12 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT284, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,727 PROKIT-TC30 Axis Travel (Maximum): 12 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, CT304, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,987 PROKIT-TC31 Axis Travel (Maximum): 12 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 32, FT32(tape), Universal Lathe-M, T-arm (two) EC 6 PD List Price: $5,766 14" Travel Slim-Line Scale for X PROKIT-TC32 Axis Travel (Maximum): 14 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT102, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,851 PROKIT-TC33 Axis Travel (Maximum): 14 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT124, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,966 PROKIT-TC34 Axis Travel (Maximum): 14 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT134, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,168 PROKIT-TC35 Axis Travel (Maximum): 14 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT154, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,284 PROKIT-TC36 Axis Travel (Maximum): 14 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT174, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,356 PROKIT-TC37 Axis Travel (Maximum): 14 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT184, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,500 PROKIT-TC38 Axis Travel (Maximum): 14 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT204, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $3,969 PROKIT-TC39 Axis Travel (Maximum): 14 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT244, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,323 PROKIT-TC40 Axis Travel (Maximum): 14 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT284, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,799 PROKIT-TC41 Axis Travel (Maximum): 14 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, CT304, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $5,045 PROKIT-TC42 Axis Travel (Maximum): 14 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 37, FT32(tape), Universal Lathe-M, T-arm (two) EC 6 PD List Price: $5,839 16" Travel Slim-Line Scale for X PROKIT-TC43 Axis Travel (Maximum): 16 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT102, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,880 PROKIT-TC44 Axis Travel (Maximum): 16 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT124, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,995 PROKIT-TC45 Axis Travel (Maximum): 16 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT134, Universal Lathe-L/Combo (two) EC 4 PD List Price: $3,212 PROKIT-TC46 Axis Travel (Maximum): 16 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT154, Universal Lathe-L/Combo (two) EC 4 PD List Price: $3,313 PROKIT-TC47 Axis Travel (Maximum): 16 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT174, Universal Lathe-L/Combo (two) EC 4 PD List Price: $3,399 PROKIT-TC48 Axis Travel (Maximum): 16 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT184, Universal Lathe-L/Combo (two) EC 4 PD List Price: $3,544 PROKIT-TC49 Axis Travel (Maximum): 16 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT204, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,034 PROKIT-TC50 Axis Travel (Maximum): 16 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT244, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,366 PROKIT-TC51 Axis Travel (Maximum): 16 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT284, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,843 PROKIT-TC52 Axis Travel (Maximum): 16 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 42, CT304, Universal Lathe-L/Combo (two) EC 6 PD List Price: $5,117 PROKIT-TC53 Axis Travel (Maximum): 16 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47 FT32(tape), Universal Lathe-L/Combo (two) EC 6 PD List Price: $5,882 18" Travel Slim-Line Scale for X PROKIT-TC54 Axis Travel (Maximum): 18 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, CT154, Universal Lathe-L/Combo (two) EC 4 PD List Price: $3,356 PROKIT-TC55 Axis Travel (Maximum): 18 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, CT204, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,005 PROKIT-TC56 Axis Travel (Maximum): 18 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, CT304, Universal Lathe-L/Combo (two) EC 6 PD List Price: $5,088 PROKIT-TC57 Axis Travel (Maximum): 18 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, FT32(tape), Universal Lathe-L/Combo (two) EC 6 PD List Price: $5,911 PROKIT-TC58 Axis Travel (Maximum): 18 X 135 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, FT34(tape), Universal Lathe-L/Combo (two) EC 9 PD List Price: $6,061 PROKIT-TC59 Axis Travel (Maximum): 18 X 151 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, FT38(tape), Universal Lathe-L/Combo (two) EC 9 PD List Price: $6,344 PROKIT-TC60 Axis Travel (Maximum): 18 X 160 DRO, X Scale, Z Scale, Mounting Hardware: 400i, MT 47, FT40(tape), Universal Lathe-L/Combo (two) EC 9 PD List Price: $6,560 Display Upgrades: 400i-TS (with CSS - for variable speed spindle control, and Constant Surface Speed) List Price: $866
