Fagor Automation 20i-T Lathe Prokit

20i Features

• COLOR TFT LCD
• Solid graphics
• 3D Simulation
• Distance to go
• UL approval
• 20 Tool offsets
• Direct mm/inch conversion.
• Axis RESET (to zero).
• Axis PRESET.
• Absolute / incremental.
• Taper calculation
• Data Eeprom back-up.
• Machine error compensation
• Fine/coarse display resolution. selection from Keyboard:
• 0.005 / 0.01 micron. (.0002 / .001)
• HOLD function.
• Radius/diameter.

MT Scales Features

Reader head movement on roller bearings.

Accuracy +/- 10 microns.

Maximum speed 30 m/min.

Sealing protection IP 53.

Armored cables

Threading Assistance Package Lathe threading feature for 40i DRO. Items included:

Encoder - (S2500C)

Cable for encoder (XC-C4-5-D)

Encoder coupling (AF Type)

Mounting Bracket (To be supplied by customer) (Drawing enclosed)

Fagor Prokits come standard with Display Arm for Headstock Mounting. PROKIT-T1 Display Upgrades: Innova 30i-T (3-axis Display with Compound Axis Coupling) List Price: $375 Innova 40i-TS (with CSS - for Variable Speed Spindle Control, and Constant Surface Speed) List Price: $866 6" Travel Mini-Scale for X PROKIT-T1 Axis Travel (Maximum): 6 X 36 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 17, CT92, Universal Lathe S, T-arm, EC 3 PD List Price: $2,100 PROKIT-T2 Axis Travel (Maximum): 6 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 17, CT102, Universal Lathe S, T-arm, EC 3 PD List Price: $2,129 8" Travel Mini-Scale for X PROKIT-T3 Axis Travel (Maximum): 8 X 36 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 22, CT92, Universal Lathe S, T-arm, EC 3 PD List Price: $2,129 PROKIT-T4 Axis Travel (Maximum): 8 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 22, CT102, Universal Lathe S, T-arm, EC 3 PD List Price: $2,164 PROKIT-T5 Axis Travel (Maximum): 8 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 22, CT124, Universal Lathe S, T-arm, EC 3 PD List Price: $2,308 8" Travel Slim-Line Scale for X PROKIT-T6 Axis Travel (Maximum): 8 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 22, CT134, Universal Lathe M, T-arm, (two) EC 4 PD List Price: $2,382 PROKIT-T7 Axis Travel (Maximum): 8 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 22, CT154,Universal Lathe M, T-arm, (two) EC 4 PD List Price: $2,670 PROKIT-T8 Axis Travel (Maximum): 8 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 22, CT174, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $2,741 PROKIT-T9 Axis Travel (Maximum): 8 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 22, CT204, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,174 10" Travel Mini-Scale for X PROKIT-T10 Axis Travel (Maximum): 10 X 36 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 27, CT92, Universal Lathe S, T-arm, EC 4 PD List Price: $2,158 PROKIT-T11 Axis Travel (Maximum): 10 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 27, CT102, Universal Lathe S, T-arm, EC 4 PD List Price: $2,201 PROKIT-T12 Axis Travel (Maximum): 10 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MMKT 27, CT124, Universal Lathe S, T-arm, EC 4 PD List Price: $2,346 10" Travel Slim-Line Scale for X PROKIT-T13 Axis Travel (Maximum): 10 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT134, Universal Lathe M, T-arm, (two) EC 4 PD List Price: $2,418 PROKIT-T14 Axis Travel (Maximum): 10 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT154, Universal Lathe M, T-arm, (two) EC 4 PD List Price: $2,706 PROKIT-T15 Axis Travel (Maximum): 10 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT174, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $2,827 PROKIT-T16 Axis Travel (Maximum): 10 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT184, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $2,952 PROKIT-T17 Axis Travel (Maximum): 10 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT204, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,240 PROKIT-T18 Axis Travel (Maximum): 10 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT244, Universal Lathe M, T-arm, (two) EC 6 PD List Price: $3,659 PROKIT-T19 Axis Travel (Maximum): 10 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT284, Universal Lathe M, T-arm, (two)EC 6PD List Price: $4,150 PROKIT-T20 Axis Travel (Maximum): 10 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 27, CT304, Universal Lathe M, T-arm, (two) EC 6PD List Price: $4,511 12" Travel Slim-Line Scale for X PROKIT-T21 Axis Travel (Maximum): 12 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT102, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,237 PROKIT-T22 Axis Travel (Maximum): 12 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT124, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,382 PROKIT-T23 Axis Travel (Maximum): 12 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT134, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,452 PROKIT-T24 Axis Travel (Maximum): 12 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT154, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,741 PROKIT-T25 Axis Travel (Maximum): 12 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT174, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,815 PROKIT-T26 Axis Travel (Maximum): 12 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT184, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,995 PROKIT-T27 Axis Travel (Maximum): 12 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT204, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $3,313 PROKIT-T28 Axis Travel (Maximum): 12 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT244, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $3,688 PROKIT-T29 Axis Travel (Maximum): 12 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT284, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,184 PROKIT-T30 Axis Travel (Maximum): 12 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, CT304, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,554 PROKIT-T31 Axis Travel (Maximum): 12 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 32, FT32(tape), Universal Lathe-M, T-arm (two) EC 6 PD List Price: $5,276 14" Travel Slim-Line Scale for X PROKIT-T32 Axis Travel (Maximum): 14 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT102, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,273 PROKIT-T33 Axis Travel (Maximum): 14 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT124, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,418 PROKIT-T34 Axis Travel (Maximum): 14 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT134, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,490 PROKIT-T35 Axis Travel (Maximum): 14 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT154, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,779 PROKIT-T36 Axis Travel (Maximum): 14 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT174, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $2,851 PROKIT-T37 Axis Travel (Maximum): 14 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT184, Universal Lathe-M, T-arm (two) EC 4 PD List Price: $3,024 PROKIT-T38 Axis Travel (Maximum): 14 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT204, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $3,392 PROKIT-T39 Axis Travel (Maximum): 14 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT244, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $3,717 PROKIT-T40 Axis Travel (Maximum): 14 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT284, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,222 PROKIT-T41 Axis Travel (Maximum): 14 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, CT304, Universal Lathe-M, T-arm (two) EC 6 PD List Price: $4,583 PROKIT-T42 Axis Travel (Maximum): 14 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 37, FT32(tape), Universal Lathe-M, T-arm (two) EC 6 PD List Price: $5,333 16" Travel Slim-Line Scale for X PROKIT-T43 Axis Travel (Maximum): 16 X 40 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT102, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,302 PROKIT-T44 Axis Travel (Maximum): 16 X 48 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT124, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,447 PROKIT-T45 Axis Travel (Maximum): 16 X 52 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT134, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,533 PROKIT-T46 Axis Travel (Maximum): 16 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT154, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,822 PROKIT-T47 Axis Travel (Maximum): 16 X 68 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT174, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,885 PROKIT-T48 Axis Travel (Maximum): 16 X 72 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT184, Universal Lathe-L/Combo (two) EC 4 PD List Price: $3,149 PROKIT-T49 Axis Travel (Maximum): 16 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT204, Universal Lathe-L/Combo (two) EC 6 PD List Price: $3,428 PROKIT-T50 Axis Travel (Maximum): 16 X 96 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT244, Universal Lathe-L/Combo (two) EC 6 PD List Price: $3,746 PROKIT-T51 Axis Travel (Maximum): 16 X 110 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT284, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,265 PROKIT-T52 Axis Travel (Maximum): 16 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 42, CT304, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,617 PROKIT-T53 Axis Travel (Maximum): 16 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47 FT32(tape), Universal Lathe-L/Combo (two) EC 6 PD List Price: $5,377 18" Travel Slim-Line Scale for X PROKIT-T54 Axis Travel (Maximum): 18 X 60 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, CT154, Universal Lathe-L/Combo (two) EC 4 PD List Price: $2,880 PROKIT-T55 Axis Travel (Maximum): 18 X 80 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, CT204, Universal Lathe-L/Combo (two) EC 6 PD List Price: $3,500 PROKIT-T56 Axis Travel (Maximum): 18 X 120 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, CT304, Universal Lathe-L/Combo (two) EC 6 PD List Price: $4,684 PROKIT-T57 Axis Travel (Maximum): 18 X 127 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, FT32(tape), Universal Lathe-L/Combo (two) EC 6 PD List Price: $5,449 PROKIT-T58 Axis Travel (Maximum): 18 X 135 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, FT34(tape), Universal Lathe-L/Combo (two) EC 9 PD List Price: $5,766 PROKIT-T59 Axis Travel (Maximum): 18 X 151 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, FT38(tape), Universal Lathe-L/Combo (two) EC 9 PD List Price: $5,983 PROKIT-T60 Axis Travel (Maximum): 18 X 160 DRO, X Scale, Z Scale, Mounting Hardware: 20iT, MT 47, FT40(tape), Universal Lathe-L/Combo (two) EC 9 PD List Price: $6,272
