Description

UHP900

Ultra-high Performance Machining Center


  • High-rigidity design, with reinforced ribs using a triangular structure for excellent rigidity and stability.

    • Automation

    Standard Configuration

  • Direct drive spindle BT40/SK40/CAT40 12000 rpm_9/22kW_63/135Nm (SIEMENS / HEIDENHAIN)

  • Direct drive spindle BBT40/SK40/CAT40 12000 rpm_11/18.5kW_52.5/118Nm (FANUC)

  • 24 pockets arm type tool changer, BT40/SK40/CAT40

  • Roller type linear guideways on all axis

  • Telescopic covers for linear axis

  • Full enclosed splash guard

  • Chain type chip conveyor

  • Spindle oil cooler

  • Air-condition electrical cabinet

  • Rigid tapping

  • Automatic lubrication system

  • Coolant system

  • Air blast during cutting

  • LED working lamp

  • End of program light

  • Electrical handwheel (MPG)

  • Tool box

  • Leveling bolts and blocks

  • Coolant gun

  • Air gun

  • User manual (mechanical + electrical parts)

  • Ethernet, CF card and USB interface

    • Optional Configuration

  • Built-in spindle HSK A63 20000rpm_20/24kW_48/58Nm (SIEMENS / HEIDENHAIN)

  • Direct drive spindle BBT40/SK40/CAT40/HSK A63 15000 rpm_9/22kW_63/135Nm (SIEMENS / HEIDENHAIN)

  • Direct drive spindle BBT40/SK40/CAT40/HSK A63 15000 rpm_9/15kW_57.3/119Nm (FANUC)

  • 24 pockets arm type tool changer, BT50/SK50/CAT50

  • 28 pockets arm type tool changer, BT40/SK40/CAT40

  • 30 pockets arm type tool changer, BT40/SK40/CAT40/HSK A63

  • 40 pockets chain type tool changer, BT40/SK40/CAT40

  • Additional rotary 4th axis

  • Additional rotary 4/5th axis

  • Linear scales on X/Y/Z axis

  • CTS coolant through spindle + ATS

  • Workpiece probe

  • Tool probe

  • Oil mist collector

  • Oil skimmer

  • Extra 200GB SSD program memory (only available on SIEMENS)

    • Specifications

    ManufacturerPRIMINER
    ConditionNew
    Control SystemSiemens / Heidenhain
    Table Size1,060 x 600 mm (41.73” × 23.62”)
    T slot [width x distance x number]18 × 100 × 5mm (0.71” × 3.94” × 0.20”)
    Max. load800 kg (1,764 lb)
    X/Y/Z travel900 / 600 / 600 mm (35.43” / 23.62” / 23.62”)
    X/Y/Z rapid feedrate36 m/min
    Spindle nose to table150 ~ 750 mm (5.91” ~ 29.53”)
    TaperBBT40/SK40/CAT40
    Spindle motor power9 / 22 kW
    Spindle motor torque63 / 135 Nm
    Spindle speed12,000 rpm
    CapacityDT24 pockets
    Tool diameterØ78 / Ø125 mm (Ø3.07” / Ø4.92”)
    Tool length300 mm (11.81”)
    Tool weight8 kg (17.64 lb)
    Dimension3,850 x 2,340 x 3,000 mm (151.57” × 92.13” × 118.11”)
    Weight6,500 kg (14,330 lb)
