V18

High Rigidity Machining Center

Fully enclosed tool magazine cover and full enclosure protection for the machine

More efficient chip removal system

Optimized coolant tank structure design for better filtration and easier maintenance

Optimized pipeline installation with drag chain to extend the lifetime

Automation

Standard Configuration

Belt drive spindle BT50/SK50 6000 rpm_17/42 kW_183/400Nm

Belt drive spindle BT50/SK50 6000 rpm_15/20.3 kW_143/259Nm

24 pockets arm type tool changer, BT50/SK50

Full enclosed splash guard

Telescopic covers for linear axis

Two screw type and one chain type chip conveyor

Spindle oil cooler

Air-condition electrical cabinet

Rigid tapping

Automatic lubrication system

Coolant system

Air blast during cutting

LED working lamp

End of program light

Electrical handwheel (MPG)

Tool box

Leveling bolts and blocks

Coolant gun

Air gun

User manual (mechanical + electrical parts)

Ethernet, CF card and USB interface

Optional Configuration

32 pockets chain type tool changer, BT50/SK50/CAT50

Additional rotary 4th axis

Additional rotary 4/5th axis

Linear scales on X/Y/Z axis

CTS Coolant through spindle + ATS

Gear box Spindle 6000 rpm

Workpiece probe

Tool probe

Oil mist collector

Oil skimmer

Extra 200GB SSD program memory (only available on SIEMENS)

Manufacturer	PRIMINER
Condition	New
Control System	Siemens
Table Size	2,000 x 900 mm (78.74” × 35.43”)
T slot [width x distance x number]	22 × 165 × 5mm (0.87” × 6.50” × 0.20”)
Max. load	2,000 kg (4,409.25 lbs)
X/Y/Z travel	1,800 / 900 / 800 mm (70.87” / 35.43” / 31.50”)
X/Y/Z rapid feedrate	20 / 20 / 15 m/min
Spindle nose to table	160 ~ 960 mm (6.30” ~ 37.80”)
Spindle Taper	SK50 / BT50 / CAT50
Spindle motor power	17 / 42 kW
Spindle motor torque	183 / 400 Nm
Spindle speed	6,000 rpm
Capacity	DT24 pockets
Tool diameter	Ø125 / Ø245 mm (Ø4.92” / Ø9.65”)
Tool length	400 mm (15.75”)
Tool weight	15 kg
Dimension	5,722 x 3,335 x 3,440 mm (225.28” × 131.30” × 135.43”)
Weight	17,500 kg (38,580 lbs)
